Featured Functions 1. Type A Dual Feeding Device (equipped with tension, corona, deviation correction and rewinding & unwinding systems) 2. Full-through Forming Die-cutting Station & Conveyor Platform 3. Varnishing Unit (supports partial varnishing) 4. Die-cutting Station (realizes front and back cutting) 5. Corona Treatment System 6. Front Cold Stamping Unit 7. Rear Cold Stamping Unit 8. Waste Collection Unit   SPECIFICATION Model Unit YTP-260R-8C+1 YTP-330R-8C+1 Printing station sets 8 Gold varnishing set 1 Transmission gear cp 1/8* Maximum paper width mm 260 330 Maximum printing width mm 250 320 Printing color number C 2-12 Material thickness mm 0.04-0.4 Printing thickness mm 0.95 Printing circumference mm 190.5-460.375 Printing speed m/min 5-100 Maximum unwinding diameter mm 800 Maximum rewinding diameter mm 800 UV Curing Machine   LED UV / Traditional Mercury Lamp Machine weight Net weight： kgs 8100 9000 Gross weight： kgs 9100 10000 Power consumption & motor Main motor： kw 11 Ink distributing motor： kw 1.6 UV curing kw 47 Machine dimensions m 6.4*1.6*2.6 6.4*1.9*2.6
